Your Trusted Forged Pipe Fittings Supplier in Malaysia
With over a decade of experience, Mumtaz Energy is a leading supplier of high-quality forged pipe fittings. Our dedication to excellence has earned us regional trust. We offer a comprehensive range of forged fittings, including socket weld and threaded options such as elbows, tees, couplings, unions, caps, plugs, and bushings.
At Mumtaz Energy, we are committed to providing top-notch forged fittings tailored to your needs.
Our forged pipe fittings conform to strict international standards, ensuring superior quality and long-lasting performance. These include:
- ASME B16.11 : Forged Fittings, Socket-Welding and Threaded
- ASME B1.20.1 : Pipe Threads, General Purpose (Inch)
- MSS SP 75: High-Test Wrought Buttwelding Fittings
- MSS SP 83: Class 3000 and 6000 Pipe Unions, Socket Welding and Threaded
- MSS SP 95: Swaged Nipples and Bull Plugs
- MSS SP 79: Socket-Welding Reducer Inserts
- MSS SP 97: Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded, and Buttwelding Ends
Understanding ASME B16.11 Forged Pipe Fittings
ASME B16.11 is a crucial standard that specifies the requirements for forged pipe fittings used in piping systems. It covers dimensions, tolerances, pressure ratings, and material specifications. Fittings under ASME B16.11 are available in socket-weld and threaded forms, providing versatile solutions for various piping configurations.
These fittings are renowned for their high strength, corrosion resistance, and ability to withstand extreme temperatures, making them ideal for demanding environments. Whether you’re working on high-pressure steam lines, oil refineries, or chemical processing plants, ASME B16.11 fittings deliver the reliability you need.
As a leading supplier of ASME B16.11 forged pipe fittings in Malaysia, Mumtaz Energy delivers high-quality fittings that meet international standards, ensuring safety and performance for your projects. Contact us today to find the perfect fitting solution for your needs.
Forged Pipe Fittings Specification
| Specification | Options |
|---|---|
| Type | 45° Elbows Threaded/Socketweld 90° Elbows Threaded/Socketweld Tees Threaded/Socketweld Full Couplings Threaded/Socketweld Half Couplings Threaded/Socketweld Union Threaded/Socketweld Caps Threaded/Socketweld Plugs Threaded/Socketweld Bushings Threaded/Socketweld Nipples Threaded/Socketweld |
| Size | 1/8″ to 4″ |
| Pressure Rating | Class 2000 Class 3000 Class 6000 Class 9000 |
| Standard | ASME B16.11 : Forged Fittings, Socket-Welding and Threaded ASME B1.20.1 : Pipe Threads, General Purpose (Inch) MSS SP 75: High-Test Wrought Buttwelding Fittings MSS SP 83: Class 3000 and 6000 Pipe Unions, Socket Welding and Threaded MSS SP 95: Swaged Nipples and Bull Plugs MSS SP 79: Socket-Welding Reducer Inserts MSS SP 97: Integrally Reinforced Forged Branch Outlet Fittings – Socket Welding, Threaded, and Buttwelding Ends |
As a leading supplier of ASME B16.11 forged pipe fittings in Malaysia, Mumtaz Energy delivers high-quality fittings that meet international standards, ensuring safety and performance for your projects. Contact us today to find the perfect fitting solution for your needs.
Material Grade Standard
| Material | Standard/Grade/Symbol |
|---|---|
| Carbon Steel For high-temperature and high-pressure environments | ASTM A105 ASTM A105N ASTM A234/A234M WPB ASTM A234/A234M WPC |
| Carbon Steel Alloy Low Alloy-Steel For low-temperature service with notch toughness testing | ASTM A350 Gr LF1 ASTM A350 Gr LF2 ASTM A350 Gr LF3 ASTM A350 Gr LF5 ASTM A350 Gr LF6 ASTM A350 Gr LF9 |
| Carbon Steel and Alloy-Steel For high pressure (high yield) liquid transmission | ASTM A694 Gr F42 ASTM A694 Gr F46 ASTM A694 Gr F50 ASTM A694 Gr F52 ASTM A694 Gr F56 ASTM A694 Gr F60 ASTM A694 Gr F65 ASTM A694 Gr F70 |
| Austenitic Stainless Steels Stainless Steel | ASTM A182 Gr F304 ASTM A182 Gr F304L ASTM A182 Gr F316 ASTM A182 Gr F316L ASTM A182 Gr F316Ti ASTM A182 Gr F310 ASTM A182 Gr F310H ASTM A182 Gr F317 ASTM A182 Gr F317L |
| Ferritic-Austenitic Stainless Steels Duplex Stainless Steel & Super Duplex Stainless Steel | ASTM A182 Gr F50 ASTM A182 Gr F51 ASTM A182 Gr F53 ASTM A182 Gr F55 ASTM A182 Gr F60 ASTM A182 Gr F65 |
As a leading supplier of ASME B16.11 forged pipe fittings in Malaysia, Mumtaz Energy offers a variety of material grades that meet international standards, ensuring safety and performance for your piping system. Contact us today to find the perfect fitting solution for your needs.
Ordering Information
When ordering forged pipe fittings, it’s essential to provide the following details to ensure you receive the correct product:
Equal Tee, 2″, 3000#, SW, ASTM A105N, ASME B16.11
